Specifications
M03
Mitsubishi
A-IM4S-01
1.4m
Manual
Electrical
44.5dBi
43.1dBi
14.0 - 14.5 GHz
Horizontal or Vertical
CPI
HPA AND SSPA
VZU6994AC
350W
1+1
Comtech EF Data UT-4514
Radyne SFC1450A
NTT-EL HV9100
SDI
ASI
BISS/AES IN:SDI OUT:ASI/IP
Harmonic Prostream X
RAYDYNE DM240XR,
NEWTEC AZ110
Ericson RX8200
NTT-EL HVD 6100
100V or 200V
8KVA
Whisper Power GV8
AUDIO/COMS
Mixer:
Audio Monitor:
Coms:
Delay:
VIDEO
Switcher:
Monitors:
Router:
Signal Processor:
Sync Generator:
Recorders:
Midas Live 32
Genelec 8010A
Clear-Com Encore IF4W4 4-Channel
4-Wire to Party line Interface
Clear-Com MS -232 2 Channel Main Station
TC Electronic D22
Panasonic AW-HS50
Panasonic BT-LH1700
Ruige TLS480HD
Blackmagic Design Smart Videohub 16X16
Black Magic Design Teranex 2D
Tektronix TG 700
Panasonic AG-UMR20
Black Magic Design HyperDeck
Studio Mini
Vehicle: Toyota HiAce
Registration: OSAKA 830 Chi 6271 大阪 830 ち 6271
Size (Length x Width) : 470 cm x 191 cm
Required Work Place Dimensions: 600 cm x 400 cm
ANTENNA
Manufacturer:
Model:
Size:
Operation:
Antenna Travel:
TX Gain:
Rx Gain:
BAND/FREQ:
POLARISATION:
POWER AMPLIFIER
Manufacturer:
Type:
Model:
Max Power:
Quantity:
Upconverter:
MODULATION/ENCODING
Encoder:
Encoder Inputs:
Encoder Outputs:
Encryption:
MUX:
Modulator:
Decoders:
POWER
Inputs:
Power Consumption:
On Board Generator:
